The Commander 50V OPTO (Optical Isolation) series features a system isolates the noise and interference from the receiver for increased stability and safety. It is especially necessary in high voltage and current systems. The Commander 50V OPTO series does not supply power to your receiver. It requires 4.8 to 7.4 volts separate receiver power pack attached (depending on servo voltage rating).

Low Voltage Cut-off (12V to 48V at 0.5V increments) no need to select battery type just set the voltage the ESC should work on, by doing this, the ESC will be compatible with any future type of battery designs.

LVC= LOW VOLTAGE CUT: 120(12V) TO 480(48V)

BRK= BRAKE SETTING: 1: NO BRAKE, * 2: VERY SOFT BRAKE, 3: SOFT BRAKE, 4: HARD BRAKE, 5: VERY HARD BRAKE

AIR= ACTIVATE AIRPLANE MODE*

PCT= PROGRAM CUT TYPE (LVC TYPE): 1: CUT 50%*, 2: NO CUT JUST LED WARNING, 3: PULSE WARNING

MAT= MOTOR ACCELERATION TIME DELAY: 1: 0.15 Seconds, 2: 0.3 Seconds*, 3: 0.45 Seconds, 4: 0.7 Seconds, 5: 1.3 Seconds

CAR/B= DISABLED

COP= CURRENT OVERLOAD PROTECTION: 1: PROTECTION ON*, 2: PROTECTION OFF (CHOOSING OPTION 2 WILL VOID WARRANTY)

FREQ= DRIVE FREQUENCY: 1: 8 kHz *

SS= 1: SOFT START WITH OUT GOVERNOR MODE*, 2: SOFT START WITH GOVERNOR

TIM= MOTOR TIMING: 1: AUTO TIMING*, 2: 5 Degrees, 3: 15 Degrees, 4: 20 Degrees, 5: 25 Degrees, 6: 30 Degrees

GOV= GOVERNOR CORRECTOIN: 1: SOFT*, 2: MEDIUM, 3: STRONG

SB= MOTOR STARTING BOOSTER 1: SOFT, 2: MEDIUM, 3: STRONG

SOFT START DURATIO: 1. SHORT 10 Seconds, 2: MEDIUM 15 Seconds*, 3:STRONG 20 Seconds

*Factory Default
