Scorpion A-6528-200kv V2


Product Description

The Scorpion A - Series line of motors was designed to be the most optimal and premier choice of motor for your freestyle or UAV airplane. We have achieved incredible performance through incredible efficiency. By optimizing the magnets in the rotor, and using the best quality 0.2mm thickness silicon steel stator sheets, and 2 x single strand 1.2mm enamel coated copper wire windings rated above 200C+, the performance and efficiency results are unlike anything we have seen before! Combined with a robust design which has been tested extensively by our world class team pilots for longevity and reliability, we feel this motor checks and exceeds all measurable categories!

The A-6528-200kv was designed specifically for 85"-95" Acrobatic Airplanes, or other Sport / UAV airplanes requiring up to 6000w of power. This motor is equivalent to a 60cc/76cc gas engine. We call it 60/76cc because with a 23" prop it is very equivalent to a 60cc gas engine and pulls less amps and therefore could run smaller batteries for lighter overall model weight. Or with a 24" prop it pulls as hard as a 76cc gas engine, with more amps thus requiring a larger battery.


Recommended Prop Selection :

23x10E = Efficiency / 60cc performance

24x10E = Optimal / 70cc-76cc performance

24x12E / 25x8E = High Alt


Recommended ESC -: Tribunus II+ 14-200A ESC SBEC


Acrobatic Weight Range -: 8.18kg - 12.7kg (18.0lbs - 28.0lbs)

Sport / UAV (single engine) Weight Range : - 12.7kg - 36kg (28.0lbs -80lbs)


Scorpion A-6528-200kv + A-6528 PNP Combo {Official Promo Video}


Motor Kv 200 RPM / Volt
Weight (Motor only) 998g (35.20 oz)
Weight (including mount + Prop mount accessories) 1115g (39.33 oz)
Motor Body Dimensions 78.5 mm x 67.8mm (3.09" x 2.67")
External Shaft Diameter 10mm
Continuous Current 95A
Continuous Power 4218 Watts
Peak Current* 162A
Peak Power* 7200 Watts
Max Rated Lipo Cell** 12s
Stator Diameter 65.0 mm (2.56 in)
Stator Thickness 28 mm (1.10 in)
No. of Stator Arms 12
Magnet Poles 14
Motor Wind 6T/7T Delta
Motor Wire 2-Strand x 1.2mm
No-Load Current (IO/20V) 2.37 Amps
Motor Internal Resistance 8.4 mΩ
*Our ratings are classified as TRUTHFUL. Continuous Current / Power correlates to actual sustainable power levels. Peak Power is for intermittent full throttle usage ranging from 5 - 60 seconds depending on use case and cooling*
**Higher Cell Count possible with smaller prop usage**

Included in the Box

1 x Scorpion A-6528 BLDC Motor
1 x A-55/65 Cross Mount (stock)
4 x M4 Cross Mount Mounting Bolts
3 x Female 6mm Connectors
3 x Heat Shrink
3 x Scorpion Stickers
2 x M10 Nuts

Weight including packaging


Full Dimension

View Scorpion A-6528-200kv V2 Full Dimension
