Scorpion MII-3011-1100kv (8"-9" / Cinematography Edition)
- Overview
- Technical specifications
- Videos
The new Scorpion MII-3011 Cinematography Edition is a purpose built motor, designed specifically for 8"-9" prop cinelifters. This motor checks every box you would need it to for your cinematic build.
High Power / High Torque / Unmatched Efficiency / Ultra Smooth / Low Noise
Designed specifically for props such as HQ 8x4x3 and similar on 6s power, this motor has a power density like we have never seen before, and unmatched thrust measuring up to 3200g of thrust till the end of the battery. While most cinelifter builds fly as a X8 coaxial configuration, with MTOW of 4kg, our test results show amazing performance with even an X4 configuration flying at 3.5kg. Accounting for coaxial loss, as a X8 configuration, this motor could fly up to 4.5-5kg MTOW with ease.
Full Dimension
Specifications
| Motor Kv | 1100 RPM / Volt |
| Weight (incl. 25cm wire) | 90g (4.80 oz) |
| Motor Body Dimensions | 27.3 mm x 36.8mm (1.07" x 1.45") |
| External Shaft Diameter | 4.98mm x 16mm |
| Continuous Current | 38A |
| Continuous Power | 844 Watts |
| Peak Current | 60A |
| Peak Power | 1332 Watts |
| Max Rated Lipo Cell | 4-6s |
| Stator Diameter | 30.0 mm (1.18 in) |
| Stator Thickness | 11 mm (0.67 in) |
| No. of Stator Arms | 12 |
| Magnet Poles | 14 |
| Motor Wind | 8T Delta |
| Motor Wire | 10-Strand x 0.25 |
| No-Load Current (IO/15V) | 1.6 Amps |
| Frequency | 48khz |
| Timing | 24deg |
| Motor Internal Resistance (phase-phase) | 55 mΩ |
| Motor Inductance (phase-phase) @ 1khz | 13.6µH |
| *Our ratings are classified as truthful. Continuous Current / Power correlates to actual sustainable power levels. Peak Power is for intermittent full throttle usage ranging from 5 - 60 seconds depending on use case and cooling* | |
| **Higher Cell Count possible with smaller prop usage** | |
Performance Charts
.png)
.png)
.png)
.png)
.png)
Included in the Box
Scorpion MII-3011 BLDC Motor
M5 Lock Nut
Prop Washer
M3 Mounting Hardware
3 x Scorpion Stickers
Weight including packaging
168g
